Oxygen Concentrator 5L

A mains electricity powered device that concentrates oxygen from ambient air and delivers the concentrated oxygen in a controlled manner to a patient requiring oxygen therapy, up to 5 L/min.

General description

Oxygen concentrator, 5 LPM – single flow

Important Information

Oxygen concentrators are not suitable for use as an oxygen source for other medical equipment providing respiratory support, such as ventilators, CPAP devices, High Flow Nasal Cannula, etc.

The technical specifications listed below are the minimum requirements that concentrators can perform and fulfill according to WHO requirements. The detailed technical specifications and contents for each concentrator model may be slightly different. Therefore, information relating to the  specific product model i.e. product brochure, package insert, etc. to be supplied  will be sent to the Principal Recipient for acceptance and  approval prior to ordering

Technical Specifications

Provides a continuous, variable flow of concentrated oxygen (>82%) derived from room air, to a maximum rate of 5 L/min.

Contains oxygen monitor to verify concentration.

Equipped with one oxygen outlet, provided with controllable flowmeter.

Audible and visual alarms for low oxygen concentration (<82%) and power supply failure.

Audible and visual alarms for high temperature, no flow rate and low/high pressure.

Flowmeter continuously adjustable, with markings of at most 0.5 L/min intervals.

AC 100-120V 60Hz, 220-240V 50Hz

Quality Standards

ISO 13485

DIRECTIVE 93/42/EEC

Items minimally supplied with

Oxygen Concentrator 5L  – 1 piece

Oxygen cannula  – 2 pieces

Humidifier Bottle – 1 piece

Air-intake filter-gross filter – 1 piece

Secondary filter-inlet filter  – 1 piece

User Manual  – 1 piece

Power cord  – 1 piece

Quality certificate  – 1 piece

Storage conditions

Temperature: 0 °C to 40 °C,

Relative humidity: 15% to 85%

Elevation above sea level: 0 to 2000m

Operating conditions

Temperature: 10 °C to 40 °C,

Relative humidity: 15% to 85%

Elevation above sea level: 0 to 2000m

Installation requirements

The User Manual supplied with the device details all installation which can be undertaken by users.

User training requirements

The User Manual supplied with the device details all operation procedures for user.

Technical training requirements

The User Manual supplied with the device details all maintenance and troubleshooting procedures which can be undertaken by users.

Note: Contact Iplussolutions if additional installation and training requirements are required beyond user manual

Warranty Period

2 years
